Visoglide (VG)

Characteristic of the system

System for lift and sliding patio doors with thermal break.The profiles consist of 2 aluminium extursions which are separated from one another by polyamide strips PA 6. 6. 25 reinforced with glass fibre. A gluing thread, rooled and pushed in together with the thermal break profile ensures a strong adhesion after melting and flowing, when the profiles are heated in the hardening furnace.
Three chamber profiles. Ability different combinations: 2-,3-,4-,and 6-parted. Built-in depth: outer frame 99 mm. Glazing: from 4 to 29 mm. Hardware: Sobinco.Max. sash weight: 200 kg.

Applications

– to separate terrace and living quarters in houses and flats
– separations for conservatories looking out into the garden and to create space in a passage way
